1553B屏蔽双绞线缆
| |
 |
| |
| |
常温导线 |
高温导线 |
| 产品号 |
30-02001 |
30-02003 |
M17/176-00002 |
30-02002 |
| 特征阻抗(Ohms) |
78 ± 3 |
78 ± 3 |
77 ± 7 |
77 ± 7 |
| 外径 |
0.242 |
0.150 |
0.129 |
0.095 |
| 内部导线直径 |
0.037 |
0.022 |
0.024 |
0.0149 |
| 温度范围 |
-20°C to +75°C |
-20°C to +75°C |
-55°C to +200°C |
-55°C to +200°C |
| 最小弯曲半径 (inches) |
2.42 |
1.50 |
1.50 |
1.25 |
| 特征电容{pF/ft.) |
19.7 |
20.3 |
24 |
23 |
Attenuation
1Mhz (dB/100 ft.) |
0.6 |
2 |
1.4 |
2 |
| 导线外皮材料 |
PVC |
PVC |
Teflon |
PFA |
| 绝缘材料 |
PVC |
PVC |
Teflon |
FEP |
| 屏蔽率 |
93% |
93% |
90% |
90% |
| 配套MilesTek插头 |
| |
